Using Azure File Storage as Container Volume Mounts in App Services

Need to scale your app? Put it in a container. Need more resiliency? Put it in a container. Code starting to smell? Put it in a container. Want some lunch? Put it in a container.

Okay. Containerization is pretty great, but once you start dealing with saving data and/or files you realize you need to add volumes to the mix. Docker volumes provide access to external resources, such as storage, in a way that seems local to the container. Mapping a local drive on the host to the container is as simple as adding a line or two to a docker-compose.yml file.

But what happens when you move to the cloud? Specifically, let's talk about Azure. If you've got files to save in Azure, you're probably using Azure Storage. Azure Storage provides a number of great features at a very competitive price, but how can we access those files within a container running in an Azure App Service? Read on to learn.

Azure File Storage

Azure Add File Share window

First, let's setup Azure File Storage. If you already have File Storage you'd like to use, then skip to the next section.

From your Azure Portal, add a new Storage Account. In your Storage Account, click on the "File shares" blade. Then press the "+ File Share" button at the top. Choose a name for your file share and press "Create."

Configuring Your Azure App Service

Azure App Service path mappings interface

We'll assume you already have an Azure App Service you're ready to configure.

In your App Service, click on the "Configuration" blade. Then click the "Path mappings" tab. Under path mappings you can click the "+ New Azure Storage Mount" option.

Let's review the "New Azure Storage Mount" interface.

Azure New Storage Mount interface

Name is important. This is the name you'll use to reference this mount later in your docker-compose.yml

For our purposes, we'll use the Basic Configuration option.

Choose your existing Storage Account where your file share lives.

For Storage Type, select "Azure Files" and then select the file share you previously created as the Storage container.

Mount path is the path within your file share that you'd like to mount. If you want to mount the entire file share, enter "/". Otherwise, specify the directory path you'd like to mount.

Finally, press the "Ok" button to setup your storage mount.

Tell Docker About It

Our final step is to configure our docker-compose.yml to tell our container how to use this storage mount as a volume.

You need to add a "volumes" property under the service needing the mount. The volumes property is a list in the following format: {mount name provided above}:{path within the container}.

So if you had a service named "web" and you had created a storage mount named "data," your docker-compose.yml might look like the following:

version: "3.7"

services:
    web:
        image: wordpress
        container_name: web-wordpress
        init: true
        restart: always
        ports:
            - "80:80"
        volumes:
            - data:/var/www/html

Wrap It Up

Azure has made this a fairly straight-forward process, but finding this information was extremely painful. No Google-Fu produced the answers so I knew I needed to write this down to remember it next time.

Have some feedback or questions? Leave a comment or find me on Twitch several days a week at https://twitch.tv/BaldBeardedBuilder.

Comments

avatar
  1. Avatar for Francis
    Francis   |  August 13, 2020
    Thank you very much for this post. I've been looking for this information for days! It's a shame that Azure official documentation is not clear about that.
  2. Avatar for Michael Jolley
    Michael Jolley   |  August 14, 2020
    Glad it helped Francis and thanks for letting me know you got some value out of it!
  3. Avatar for Divi
    Divi   |  September 30, 2020
    Thanks for the article, just wanted to check don't we need to add declaration like following : ? volumes: data: because else docker-compose throws following error Named volume "data:/var/www/html/logs/:rw" is used in service "web" but no declaration was found in the volumes section. Secondly, Addition to following the article, I tried declaring the volumes, docker-compose build/push-ed. The logs folder I have inside docker container DO NOT got copied to my AzureFiles, instead I got a huge <name>.img file Please share some insight what is full process
  4. Avatar for Michael Jolley
    Michael Jolley   |  October 6, 2020
    Hi Divi. You shouldn't have to specify the volumes separately in the docker-compose. You can list it under the service as I show in the blog post. However, it is VERY important that you make sure the name you gave in the New Azure Storage Mount dialog matches the name in the docker-compose. Spelling & casing should match. In my example I entered "data" as the Name. As for your second question, it's hard to identify what you're experiencing without seeing some code. Feel free to reach out via a Twitter DM with more information.
  5. Avatar for José Romualdo
    José Romualdo   |  November 5, 2020
    Hi guy! I have been working in two last days over a problem of volume mount in webapps and I found the solution here. Thanks for share your solution with us!
